COUGAR FV270 RGB MID Curved Tempered Glass - Black

Product Name

FV270 RGB / FV270 RGB (White)

Case Form Factor

Mid Tower

Motherboard Type

Mini ITX / Micro ATX / ATX / CEB / E-ATX

Dimensions (WxHxD)

268 x 530 x 512 mm
10.6 x 20.9 x 20.2 in

I/O Panel

Type C Gen 2 x1, USB 3.0 x2, 4-Pole Headset Audio Jack, RGB Button

3.5" Drive Bay

2

2.5" Drive Bay

2 + 2 (converted from 3.5" drive bays)

Expansion Slots

7 (horizontal slots can be converted into vertical slots)

Vertical GPU Support

Yes

Cooling Fan Support – Top

120mm x3 / 140mm x2

Cooling Fan Support – M/B Side

120mm x2 / 140mm x2

Cooling Fan Support – PSU Shroud

120mm x2 / 140mm x2

Cooling Fan Support – Bottom

120mm x1

Cooling Fan Support – Rear

120mm x1 / 140mm x1

Pre-installed Fans – M/B Side

140mm Reversed ARGB PWM fan x2

Pre-installed Fans – Bottom

120mm Reversed ARGB PWM fan x1

Pre-installed Fans – Rear

140mm ARGB PWM fan x1

Fan Speed

500 (±200) – 1200 (±10%) RPM

Fan Connector

5V 3-Pin (ARGB) / 4-Pin (Fan)

Maximum Number of Fans

9

Water Cooling Support – Top

360mm / 280mm / 240mm / 140mm / 120mm

Water Cooling Support – M/B Side

280mm / 240mm / 140mm / 120mm

Water Cooling Support – PSU Shroud

240mm / 120mm

Water Cooling Support – Bottom

-

Water Cooling Support – Rear

140mm / 120mm

PWM and RGB Hub Sync with M/B

Yes

Max. Graphics Card Length (Horizontal)

420 mm / 16.5 in (Only fans at M/B Side)
330 mm / 13 in (Radiator with fans at M/B Side)

Max. Graphics Card Length (Vertical)

450 mm / 17.7 in

Max. CPU Cooler Height

180 mm / 7.1 in

Max. PSU Length

250 mm / 9.8 in
