ASUSTOR AS1102T DRIVESTOR 2-BAY NAS Server
SPECIFICATION
|
CPU |
|
|
CPU Model |
Realtek RTD1296 |
|
CPU Architecture |
ARM64 64-bit |
|
CPU Frequency |
Quad-Core 1.4GHz |
|
Memory |
|
|
Memory |
1GB DDR4 |
|
Memory Expandable |
Not expandable |
|
Flash Memory |
8GB eMMC |
|
Storage |
|
|
Drive Bays |
2 |
|
Compatible Drive |
3.5" SATA HDD |
|
Maximum Drive Bays with Expansion Unit |
10 |
|
External Ports |
|
|
Expansion |
2x USB 3.2 Gen 1 |
|
Network |
1x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
|
Multimedia Output |
N/A |
|
Others |
|
|
System Fan |
1x 70mm |
|
Power Supply Unit / Adapter |
65W x1 |
|
Input Power Voltage |
100V to 240V AC |
|
Certification |
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC |
|
Warranty |
3 Years |
|
Operation |
|
|
Power Consumption |
11.6W (Operation), 5.97W (Disk Hibernation) |
|
Noise Level |
18.6dB (HDD idle) |
|
Operation Temperature |
0°C |
|
Storage Temperature |
-20°C |
|
Humidity |
5% to 95% RH |
|
Size and Weight |
|
|
Size |
165(H) x 102(W) x 218(D) mm |
|
Weight |
1.14 kg / 2.5 lbs |
|
Supported OS |
Windows 7, 8, 10, 11, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022, macOS, UNIX, Linux, BSD |
|
Supported Languages |
Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย |
|
Supported Browsers |
Firefox, Chrome, Safari, Microsoft Edge |
|
Network |
|
|
Network Protocols |
CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog |
|
Connection and Transmission |
TCP/IP (IPv4 & IPv6), Link Aggregation: 0, Jumbo Frame (MTU), VLAN, EZ Connect, Wireless Network, DDNS and EZ-Router, Supports Wake-on-LAN (WOL), Supports Wake-on-WAN (WOW) |
